LED OPERATION LAMP
LED OPERATION LAMP K6 & K3
K6 & K3
- K6
K3
|
Model Technical index |
K6 |
|
Light Head Diameter |
62 cm |
|
Articulation Radius |
170 / 183 / 198 cm Or by order |
|
Light Head Height Adjustment |
105 cm |
|
Illuminate Mode |
Reflect LED |
|
Central Illuminance / 1m |
0 ~ 160,000Lux / each |
|
MIS (ENDO Light) |
0 ~ 28,000Lux |
|
Color temperature |
4300°K (±300) |
|
Color Rendering Index |
92 (±4) |
|
Focusable Light Head Height |
60 ~ 180 cm |
|
Depth of Light |
60 cm |
|
Depth of Illumination (L1+L2) |
110 cm |
|
Light field diameter |
15 ~ 27 cm |
|
LED Quantity (each light head) |
36 |
|
LED Life |
50,000Hrs |
|
Heat to Light Ratio |
2.6mw / m²lux |
|
Maximum Power |
36W At 160,000Lx / 1m |
|
Power Supply |
AC100 ~ 240V |
|
(Color Temperature 3800°K warm white light is optional) |
|
|
Model Technical index |
K3 |
|
Light Head Diameter |
20 cm |
|
Articulation Radius |
163 cm Or by order |
|
Light Head Height Adjustment |
105 cm |
|
Illuminate Mode |
Reflect LED |
|
Central Illuminance / 1m |
0 ~ 70,000Lux / each |
|
MIS (ENDO Light) |
-- |
|
Color temperature |
4300°K (±300) |
|
Color Rendering Index |
92 (±4) |
|
Focusable Light Head Height |
50 ~ 180 cm |
|
Depth of Light |
80 cm |
|
Depth of Illumination (L1+L2) |
130 cm |
|
Light field diameter |
12 ~ 20 cm |
|
LED Quantity (each light head) |
7 |
|
LED Life |
50,000Hrs |
|
Heat to Light Ratio |
2.6mw / m²lux |
|
Maximum Power |
18W At 70,000Lux / 1m |
|
Power Supply |
AC100 ~ 240V |
|
(Color Temperature 3800°K warm white light is optional) |
|
